GTU-5000 device is perfectly suitable for advanced tracking of passenger vehicles and light/heavy-duty trucks.
Location and tracking
GTU-5000 supports almost all major navigation systems and can be used all over the world.
This device supports 3 separate variables for track detection giving you full flexibility over trip detection.
- 72-channel GPS, Glonass, Beidou
- Continuous tracking mode (distance/time/angle)
- Assisted GPS
- LBS
Mobile networks
GTU-5000 supports wide range of networks from 2G to 4G ensuring global coverage even in remote areas.
- GSM Quad-band 850/900/1800/1900 MHz
- HSPA Global: B1/B2/B5/B6/B8 MHz
- LTE CAT-M1/NB/2G (Opt): B2, B3, B4, B8, B12, B13, B20, B28 MHz
- LTE CAT-1: B1, B2, B3, B4, B5, B8, B17, B20, B28 MHz
Power supply
Device utilizes standard external power supply.
Internal battery allows the device stays connected in emergencies.
- LI-PO 950mAh, Battery
- Operating Voltage: 9-32 VDC operational for 12V & 24V
Inputs and outputs
Device has a wide range of inputs and outputs which makes is perfectly customizable for your business needs.
Device can be enhanced with a variety of accessories and sensors.
It can be used to track door states, fuel and temperature sensors. Obtain diagnostic information with CANBUS. Device offers a possibility to connect emergency button for quick reaction and assistance times.
- 4 digital inputs
- 3 analog inputs
- Ignition input
- 1-wire interface
- 1 TTL/1 RS232 or RS485/CANBUS
- 3 Digital outputs
Other features
GTU-5000 has an IP67 waterproof casing and proximity sensor that detects dismantle events.
Device can be easily mounted with use of adhesives or bolts.
- Tie Wrap, Bolt, Velcro or adhesive mounts
- Built-In GSM & GPS Antenna
- 8-Mbit memory
- Status LEDs
