SAT-LITE 4 (SLXT/SLXU)
Server connection
| EU platform | tracker.navixy.com (52.57.1.136) |
| US platform | tracker.us.navixy.com (13.52.37.2) |
| Server port | 47646 |
| Auto registration | Yes |
General information
| Purpose | Vehicle |
| Size | 75x55x20 mm (2.95x2.17x0.79 in) |
| Internal antenna (GNSS) | Yes |
| Internal antenna (Connection) | Yes |
Connectivity information
| Roaming status | Yes |
| Network signal level | Yes |
| Network operator ID | Yes |
| Cellular network type | GSM Quad Band |
| Cellular network generation | 2G |
Location information
| GNSS signal level | Yes |
| LBS | Yes |
| Forced GNSS location update over SMS | Yes |
| GPS | Yes |
| GLONASS | Yes |
Features
| Remote outputs control | Yes |
| Odometer | Yes |
| Motion sensor | Yes |
| Hardware key | Yes |
| Battery capacity | 250 mAh |
Interfaces
| Discrete inputs | 2 |
| Number of outputs | 1 |
| Analog sensor | Yes |
| Impulse counter | Yes |
| Frequency sensor | Yes |
| RS485 interface | Yes |
| 1-Wire interface | Yes |
| CAN/OBDII reader type | External |
