Queclink GV75
The GV75 is a compact waterproof GPS tracker designed for a wide variety of vehicle tracking applications. It has multiple I/O interfaces that can be used for monitoring or controlling external devices.
Its built-in GPS receiver has superior sensitivity and fast time to first fix. Its quad band GPRS/GSM subsystem supports 850/900/1800/1900 MHz allowing the GV75’s location to be monitored in real time or periodically tracked by a backend server and mobile devices. Its built-in 3-axis accelerometer allows motion detection and extends battery life through sophisticated power management algorithms. System integration is straightforward and simple.
Location and tracking
- u-blox GPS chipset
- Support both continuous and interval modes
- Support LBS
- Superior sensitivity and fast time to first fix
Mobile networks
- Quad-band frequency 850/900/1800/1900 MHz
- No 3G support
Power supply
- Li-Polymer 1100 mAh backup battery
- Without reporting: 280 hours
- 5 minutes reporting: 128 hours
- 10 minutes reporting: 175 hours
Inputs and outputs
- digital inputs: 2
- digital outputs: 2
- RS232 serial port
- 1-wire input
Local and remote management
The device can be managed remotely using GPRS commands.
LED Indication
Device have LED indicators for GSM, GPS and power.
Waterproof casing
IP67 compliant waterproof casing allows the device to be used in harsh conditions.
Server connection
| EU platform | tracker.navixy.com (52.57.1.136) |
| US platform | tracker.us.navixy.com (13.52.37.2) |
| Server port | 47764 |
| Auto registration | Yes |
General information
| Purpose | Vehicle |
| Weight | 100 g (3.53 oz.) |
Connectivity information
| Roaming status | Yes |
| Network signal level | Yes |
| Network operator ID | Yes |
Location information
| GNSS signal level | Yes |
| LBS | Yes |
| Forced GNSS location update over GPRS | Yes |
| Forced GNSS location update over SMS | Yes |
| Forced LBS location update over GPRS | Yes |
Features
| Remote outputs control | Yes |
| Odometer | Yes |
| Motion sensor | Yes |
| Hardware key | Yes |
Interfaces
| Discrete inputs | 3 |
| Number of outputs | 2 |
